Product Details
＋
● Direct radiation
● High quality tweeter
● Wide and controlled dispersion pattern
● High sensitivity: 95 dB
● Extended frequency range: 1,5 - 20 kHz
● Ferrite magnet
● Aluminum dome
● 1” aluminum voice coil
| Specifications | |
| Nominal impedance | 8 Ohm |
| Minimum impedance | 6.2 ohm @ 2.5 kHz |
| Re | 5 ohm |
| Power capacity | 15 W RMS |
| Program power | 30 W |
| Sensitivity | 95 dB 1 W @ 1 m |
| Frequency range | 1500-20000 Hz |
| Recom. crossover frequency | 2 kHz or higher (12dB/oct min slope) |
| Dispersion HxV | 60º |
| Voice coil diameter | 25.4 mm 1 in |
| Flux density | 1.45 T |
| BL factor | 3 N/A |
| Dome material | Aluminio / Aluminium |
Construction |
|
| External diameter | 102 mm 3.9 in |
| Bolt circle diameter | 90 mm 3.54 in |
| Baffle cutout diameter | 75 mm 2.95 in |
| Depth | 42 mm 1.65 in |
| Net weight | 0.66 kg 1.45 lb |
| Total weight | 0.7 kg 1.54 lb |
| Magnet | Ferrite |
